Manitou 260 TJ

Working height: 25.89 m
Platform height: 23.89 m
Maximum outreach: 19.70 m
Platform weight*: 16710 kg
Platform dimensions (length x width): 2.30 m x 0.90 m
Floor height (access): 0.48 m
Platform capacity: 408 kg
Turret rotation: 360 °
Platform rotation (right / left): 90 ° / 90 °
Number of people (indoor / outdoor): 3 / 3

Add to wishlist

Description

Boost productivity at height with the Manitou 260 TJ+ all-terrain MEWP.Increase your productivity at height with the Manitou 260 TJ+, a cutting-edge all-terrain telescopic boom lift. Offering a vertical reach of 25.89 m (84.9 ft) and a horizontal outreach of 19.70 m (64.6 ft), this robust machine can accommodate up to 3 operators and a 408 kg (900 lbs) load. Ideal for the most demanding environments, the 260 TJ+ ensures optimal safety and remarkable efficiency for construction, industrial maintenance, and large-scale events. Its compact design and off-road capabilities make it essential equipment.

Capacities

Working height: 25.89 m
Platform height: 23.89 m
Maximum outreach: 19.70 m
Pendular arm rotation (top / bottom): +70 ° / -63 °
Platform capacity: 408 kg
Turret rotation: 360 °
Platform rotation (right / left): 90 ° / 90 °
Number of people (indoor / outdoor): 3 / 3

Weight and dimensions

Platform weight*: 16710 kg
Platform dimensions (length x width): 2.30 m x 0.90 m
Floor height (access): 0.48 m
Overall length: 10.84 m
Overall width: 2.48 m
Overall height: 2.71 m
Overall length (stowed): 7.88 m
Overall height (stowed): 2.80 m
Jib length: 2.40 m
Counterweight offset (turret at 90Â°): 1.43 m
External turning radius: 4.35 m
Ground clearance at centre of wheelbase: 0.42 m
Wheelbase: 2.80 m

Performances

Drive speed – stowed: 4.50 km/h
Drive speed – raised: 0.80 km/h
Gradeability: 35 %
Permissible leveling: 4 °

Wheels

Tires type: Solid tires
Standard tires: 40 x 14 in / 1025 x 365 mm
Drive wheels (front / rear): 2 / 2
Steering wheels (front / rear): 2 / 2
Braking wheels (front / rear): 2 / 2

Engine/Battery

Engine brand / model: Yanmar – 4TNV88C
Engine norm: Stage V
Engine power (Hp / kW): 46 Hp / 34.30 kW

Miscellaneous

Ground Pressure: 21.30 dan/cm2
Hydraulic Pressure: 400 bar
Hydraulic tank capacity: 94 l
Fuel tank: 76 l
Sound pressure level (platform work station) (LpA): 79 dB
Daily consumption **: 7 l

Standards compliance

This machine is in compliance with:: European directives: 2006/42/EC- Machinery (revised EN280-1:2022) – 2004/108/EC (EMC) – EMC according to EN 12895 / 2015 +A1 / 2019
